Let's See Your Semi-Custom Tikka Builds

Joined
Dec 30, 2014
Messages
8,177
Correct. If you're buying a new gun I would say buy a 7mm Rem Mag or 300 win mag. That'll get you the magnum bolt face and long action bolt stop. Then buy the Mountain Tactical magazine.
I think he's asking about an xbolt still, not a tikka.

So from what I’m getting here is 30.06 factory mag would work with factory 7prc and the receiver will work. So all I’d need to buy is a magnum bolt and a barrel correct?

Are you still asking about xbolt scenario? If so, no. An xbolt 30-06 mag will likely not work well with the fatter PRC rounds but the PRC should work with other magnums of similar case diameter like 7rm and 300wm.

I dont know the answers to a couple factors with xbolts that you would need to verify before jumping into such a project.
1. Is the receiver used for magnums the same as the receiver used for 30-06 family cartridges?
1a. Can they use bolts with Long action standard bolt face and long action magnum bolt face interchangingly?
1b Is there anything different with the feed ramps between standard and magnum long actions?
2. Is the bottom metal on an xbolt 30-06 and 300wm the same and I.E both magazines fit into it the same.

I suggest you start a new thread about this possibility because this is a tikka thread and people responding think you're talking about a tikka.

Last edited:

LRI_Chad

FNG
Joined
Jan 10, 2020
Messages
39
One I did from a few years ago:


Attachments

  • DSC_0021.jpg
    80.6 KB · Views: 149
  • DSC_0022.jpg
    79.2 KB · Views: 139
  • DSC_0023.jpg
    61.7 KB · Views: 157
  • DSC_0038.jpg
    90.5 KB · Views: 183
  • DSC_0039.jpg
    106.5 KB · Views: 185
  • DSC_0040.jpg
    64.2 KB · Views: 182
  • DSC_0041.jpg
    70.9 KB · Views: 165
  • DSC_0042.jpg
    85.7 KB · Views: 168
  • DSC_0043.jpg
    88.4 KB · Views: 160
  • DSC_0044.jpg
    111.7 KB · Views: 160
Joined
Mar 6, 2016
Messages
337

T3 action, 18” X-caliber 6.5cm prefit, krg stock, yo Dave trigger spring, area 419 rail on left (still shopping for glass)
T3x stainless action and factory 6.5 barrel threaded with MBM brake, yo Dave trigger spring, can’t remember bottom metal, Murphy precision rail, seekins rings, 2-20 nx8 f1, Allterra stock

T3X .223, takeoff CTR rail, Seekins rings, yo Dave trigger spring, now wearing an NXS 2.5-10 and SRS Hunter Rail

T3X stainless action, Mcgowan prefit 20” factory contour 300wsm barrel flared and threaded, Murphy precision rail, seekins rings, high desert bottom metal, mountain tac mags, yo Dave trigger spring, Allterra stock, now wearing an NXS 2.5-10.


Sent from my iPhone using Tapatalk


Kimmo H

FNG
Joined
Jan 3, 2023
Messages
54

Here is my t3x 6,5 Creedmoor. Started out as a Veil model. Changed the barrel to a Lothar Walther stainless, 19", contour very close to CTR barrel profile. 5/8x24 threads for a Ase Utra Radien suppressor. Leupold VX-5HD 3-15x56 on top. KKC stock, pillar bedded and with a CTR metal mags and bottom metal.

Now the question is how should I finish it up? Thinking about having it cerakoted, but can't decide on color. All steel parts matte black would be the safe way to go, but any more personal ideas are more than welcome!

Joined
Dec 28, 2019
Messages
1,582
Tikka CTR 6.5 CM 20” stainless

Mountain Tactical 20 MOA rail

Mountain Tactical trigger spring

KRG Bravo CTR Mag compatible Sako Green

KRG Minimalist Spigot to get my bipod further out towards muzzle

Spooky accurate


Attachments

  • AB32C9E0-425D-4D07-AB51-4511EC879E56.jpeg
    264 KB · Views: 169
  • 49592BDD-A8C5-47CD-BACA-D1575F2937C2.jpeg
    267 KB · Views: 176
  • 2B30267F-179C-49FF-8E72-6A3D814FF42B.jpeg
    265 KB · Views: 174
  • B9E40147-25B0-4FA3-8905-10482B870337.jpeg
    264.4 KB · Views: 167

weisenbu

Lil-Rokslider
Joined
Aug 24, 2017
Messages
203
Tikka CTR 6.5 CM 20” stainless

Mountain Tactical 20 MOA rail

Mountain Tactical trigger spring

KRG Bravo CTR Mag compatible Sako Green

KRG Minimalist Spigot to get my bipod further out towards muzzle

Spooky accurate
Do you know what the barreled action and stock together weigh? That is a nice looking setup.


kingfisher

Lil-Rokslider
Joined
Jan 20, 2016
Messages
183
I’m very interested in the Stocky’s nextgen carbon VG stocks. I have an Alterra carbon stock that I love, but they are unavailable now and I’m building another tikka and am considering the Stockys VG or waiting to see when Alterra will offer the stocks again or finding a used one.

Any info on the Stockys would be very welcome.

I really like the negative comb and the heel above the bore line on the Alterra, also the asymmetric wrist and palm swell is very natural. How does the geometry on the Stockys compare? Anyone have experience with both.

Anyone have an Alterra for sale?


Sent from my iPhone using Tapatalk
I recently reached out to Allterra. They stated they would start making their carbon stocks inleted for Tikkas again. Who knows when this will happen.

Joined
Dec 1, 2020
Messages
540
I’m reworking a 300 WSM and planning on having a Bartein barrel made for it. I have a Dead Air Armament 7.62 Sandman S (6.8”) that I plan of using. How short can I have the barrel cut?

Last edited:

Avonac

Lil-Rokslider
Joined
Oct 17, 2014
Messages
104
I’m reworking a 300 WSM and planning on having a Bartein barrel made for it. I have a Dead Air Armament 7.62 Sandman S (6.8”) that I plan of using. How short can I have the barrel cut?
I just got a 20” Carbon six. With an Omega can on it, it’s a little shorter than the factory Roughtech configuration with the factory brake. That said, I think you could go 18” and be good.


Tahoe1305

WKR
Joined
Jun 9, 2019
Messages
1,985
Location
CO
I just got a 20” Carbon six. With an Omega can on it, it’s a little shorter than the factory Roughtech configuration with the factory brake. That said, I think you could go 18” and be good.
So I agree BUT.

I called silencerco last week before I ordered my 20” C6 for a 7wsm to confirm they were holding tight to their 20” restriction on magnum calibers…..they wouldn’t budge and said would void any warranty going shorter.

So I went 20. Made me sad but I guess I get an extra 50fps and a bit less muzzle blast. Additionally in a wsm 18-20” is getting real close to 100% burn (according to QL) with most powders. I didn’t see any loads at 20 that weren’t fully burned.

EDIT: 2x BUT he’s using a dead air….disregard. ;)

Joined
Dec 1, 2020
Messages
540
So I agree BUT.

I called silencerco last week before I ordered my 20” C6 for a 7wsm to confirm they were holding tight to their 20” restriction on magnum calibers…..they wouldn’t budge and said would void any warranty going shorter.

So I went 20. Made me sad but I guess I get an extra 50fps and a bit less muzzle blast. Additionally in a wsm 18-20” is getting real close to 100% burn (according to QL) with most powders. I didn’t see any loads at 20 that weren’t fully burned.

EDIT: 2x BUT he’s using a dead air….disregard. ;)
I didn’t buy the suppressor for this rifle, that just happens to be what I have. I listed the specifics so if anyone has any experience with it or I suppose an opinion that could possibly benefit or persuade, I’m interested as it was intended to be used on an entirely different set up.
To be honest my bank account is victim of this forum, I had no idea I wanted to redo a rifle until I started reading this thread and I still have limited knowledge of what the heck I’m even doing.
So I said all that to say, I don’t speak emoji either, is there a point hiding in your post?

Bartein has don’t more than a lot of companies these days in that they actually answer the phone and try and answer questions. They did question why I would want to cut the barrel off at 18” mentioning the powder burning past that. At the time I only mentioned using a muzzle break and said I would consider adding a suppressor later.


Macintosh

WKR
Joined
Feb 17, 2018
Messages
1,934
If “semi” can be stretched a bit i guess I can play. Have 6.5mb and 270 barrels for it. 6.5 for practice and .270 to shoot factory-loaded monos a bit zippier. Both factory barrels keep 5 under an inch pretty consistently and dont seem too finicky.
Got a used mcmillan and didnt like the way it fit me. Couldnt stomach the pricetag on an eh1. So this is my ”custom” t3x lite stock w/ barrel channel opened and a takeoff CTR cheek riser and the vertical grip, it fits me a lot better this way.
CTR rail w/ seekins/vortex low rings
S&B 3-12x42 just back from getting a turret installed
SRS mini arca
8lb 6oz



gerry35

WKR
Joined
Jan 16, 2021
Messages
564
Location
Skeena Valley B.C.
Technically a "custom" Tikka, I wanted a left hand 260 Rem so I got a great deal on a RH gun and had a gunsmith put the barrel on a lightly used left hand gun he had come in. The gun shoots really well and I'm happy with how it turned out. I bought a M+ magazine and modified the bolt stop myself. Works perfectly with the way it's throated and highly recommend those with the 308 family rounds to do the same.


RAS0187

FNG
Joined
Feb 9, 2023
Messages
1
  1. Tikka T3X Light JRTXB316
Tikka T3X Stainless .308 22.4” E11AED03-84D7-4D48-A37B-F97A318904F7.jpegDNZ Game Reaper Medium One Piece Scope Mount, Leupold VX-5 HD 3-15X44 Duplex Reticle Rifle Scope - Model 171714. Installed Bell & Carlson Sporter Synthetic Stock black w/grey spiderweb. Mountain Tactical Bottom metal and Mountain Tactical 3 round billet magazine. Hardened stainless steel action screws. Butler Creek Quick Carry Sling with Swivels.
